MIKUMARI
The MIKUMARI system is a clock, timing, and synchronous command distribution system for front-end electronics (FEE) based on the clock-duty-cycle-modulation (CDCM). By distributing a modulated clock based on pulse width modulation (PWM), it is possible to transmit both clock and data on a single transmission line while achieving clock recovery independent of the clock-data-recovery (CDR) circuit. MIKUMARI consists of the CDCM based transceiver (CBT) and the link layer protocol, the MIKUMARI link. The CBT provides the functionalities of the physical layer, and the MIKUMARI link defines the communication protocol between physically connected link end points.
The MIKUMARI system is manufacture IP independent except for the serializer/de-serializer block in the CBT. Currently, the CBT is implemented for Xilinx 7-series FPGAs using the IOSERDES primitive.
Overview
The minimum configuration of the MIKUMARI system is shown in the figure. The left and right hand sides are the primary and the secondary, respectively. The purpose of the MIKUMARI system is distributing the reference clock to all the FEEs, and then a primary module must have an oscillator. To operate the system, two skew adjusted clock signals are necessary. One is the parallel clock signal to drive the parallel data path, and the other is the serial clock signal to drive the transmission line. In many cases, the reference clock will be equal to the parallel clock. The frequency ratio between the serial and parallel clock signals is defined by the modulation pattern. If the CDCM-10-XX (See Ref.) is used, the developer has to prepare the 5 times faster serial clock than that of the parallel clock, and 4 times faster clock signal is necessary for CDCM-8-XX. The maximum transferable reference (parallel) clock frequency is determined by the maximum acceptable clock frequency of the clock buffer in FPGA or the maximum data rate of IO pads. For example for Kintex-7 with the speed-grate -1 and the FBG package, the maximum BUFG speed and the maximum IO rate are 625 MHz and 1250 Mbps (HP bank case), and then the maximum transferable parallel clock speed is 125 MHz.
In the secondary side, these clock signals are reproduced from the modulated clock signal by a PLL on FEEs. Many PLL devices, i.e., PLLs in FPGA, external PLL ICs, and external jitter cleaner ICs, will work as a clock recovery circuit. To obtain the good jitter performance, the PLL of which the phase noise in low frequency region is low should be selected. The jitter distribution depends on the selected PLL device. As discussed in Ref, the obtained jitter rms when using MMCM in Kintex-7 FPGA is worse than that of the external jitter cleaner IC, CDCE62002. This comes not from the main peak structure but from the tail structure mainly. In author's opinion, MMCM is enough for 1 ns TDC synchronization, but it is not enough for high-resolution TDC with the precision around 30 ps. From the view point of the clock phase uncertainty, the PLL should have a zero-delay mode. As the CDCM technique recovers the parallel clock from the modulated clock, the phase uncertainty of the recovered clock does not appear if the PLL has the zero-delay mode. This is the important difference between the CDR circuit, which reproduced the serial clock. Unavoidable phase uncertainty exists due to the frequency division.
Since the MIKUMARI system aims to distribute the reference clock to synchronize FEEs, the connection topology of the MIKUMARI link should be a tree structure starting from a primary module. If the primary module cannot drive all FEEs, a fan-out module is necessary in intermediate layers. An example of fan-out is shown in the figure. As the CBT and the MIKUMARI link are defined as the full-duplex transceiver and the link protocol for point-to-point communication, respectively, a simple signal fan-out is not allowed. In fan-out module, the clock signals are once recovered and drive the CBTs transferring the modulated clock signal to downstream modules. In many applications, all FEEs will receive the same command from the primary module, and then TX data can be broadcasted, however, a user circuit summarizing information from the downstream modules will be necessary in the RX side. However, this is not mandatory. Since the TX and RX of the MIKUMARI link are independent, the RX port of the right side can be left open if you decide not to use the uplink data path. Since the validOutRx and frameLastOutRx signals are one-shot, the RX port and the TX ports cannot be directly connected due to the txAck cycle. Therefore, the TxElasticBuffer is necessary to connect the RX and TX ports. The TxElasticBuffer is a simple queuing buffer for adjusting CBT character transfer cycle.
The MIKUMARI link does not have a routing function, and then it does not support the end-to-end (source to destination) communication. Therefore, the clock, timing, and synchronous data transmissions are realized by repeating the point-to-point communication in the link layer. Thus, arbitrariness exists in the connection scheme inside the fan-out module. The MIKUMARI link protocol does not include experimental specific functions. It just provides the functionalities for sending a one-shot pulse with the fixed latency and the normal data transmission using the frame structure. An upper layer protocol, which gives dedicated functions for each experiment, is additionally necessary when using this system in actual experiments.
CDCM based transceiver (CBT)
The CBT is a physical layer of the MIKUMARI system. About the CBT, see also Ref. The roles of the CBT are as follows.
- Encode and decode the CDCM modulated waveform pattern
- Defines three types of CBT character using sign extension from 8-bit to 10-bit
- Initialize IOSERDES when detecting the cable (fiber) connection
- Provides the clock monitor and the error detection.
Currently, the CBT supports the CDCM-10-2.5, CDCM-10-1.5, and CDCM-8-1.5. Then, the frequency ratios between the serial and parallel clock signals are 5 for CDCM-10-XX and 4 for CDCM-8-XX with the double-data-rate (DDR) mode, respectively. The SDR mode is not supported. In addition, only the differential signal is supported.
Interface of CBT
The top-level block of the CBT is CbtLane. The global parameters for the CBT are defined in defCDCM.vhd. The CbtLane's entity port structure is as follows.
entity CbtLane is
generic
(
-- CDCM-Mod-Pattern --
kCdcmModWidth : integer; -- # of time slices of the CDCM signal
-- CDCM-TX --
kIoStandardTx : string; -- IO standard of OBUFDS
kTxPolarity : boolean:= FALSE; -- true: inverse polarity
-- CDCM-RX --
genIDELAYCTRL : boolean; -- If TRUE, IDELAYCTRL is instantiated.
kDiffTerm : boolean; -- IBUF DIFF_TERM
kRxPolarity : boolean; -- If true, inverts Rx polarity
kIoStandardRx : string; -- IOSTANDARD of IBUFDS
kIoDelayGroup : string; -- IODELAY_GROUP for IDELAYCTRL and IDELAY
kFreqFastClk : real; -- Frequency of SERDES fast clock (MHz).
kFreqRefClk : real; -- Frequency of refclk for IDELAYCTRL (MHz).
-- Encoder/Decoder
kNumEncodeBits : integer:= 2; -- 1:CDCM-10-1.5 or 2:CDCM-10-2.5
-- Master/Slave
kCbtMode : string; -- Master/Slave
-- DEBUG --
enDebug : boolean:= false
);
port
(
-- SYSTEM port --
srst : in std_logic; -- Asyncrhonous assert, synchronous de-assert reset. (active high)
clkSer : in std_logic; -- From BUFG (5 x clkPar freq.)
clkPar : in std_logic; -- From BUFG
clkIndep : in std_logic; -- Independent clock for monitor
clkIdelayRef : in std_logic; -- REFCLK input for IDELAYCTRL. Must be independent from clkPar.
clkIsReady : in std_logic; -- Indicate that clkSer and clkPar are available.
initIn : in std_logic; -- Re-do the initialization process. Sync with clkPar.
-- Status --
cbtLaneUp : out std_logic;
-- Error --
patternErr : out std_logic; -- Indicates CDCM waveform pattern is collapsed.
--idelayErr : out std_logic; -- Attempted bitslip but the expected pattern was not found.
bitslipErr : out std_logic; -- Bit pattern which does not match the CDCM rule is detected.
watchDogErr : out std_logic; -- Watch dog can't eat dogfood within specified time. The other side seems to be down.
-- Data I/F --
isKTypeTx : in std_logic; -- 1: Generate a K type character. 0: D type character.
dataInTx : in CbtUDataType;
validInTx : in std_logic; -- 1: charIn is valid. Encode and send it to CDCM-TX.
-- 0: Send idle pattern;
txBeat : out std_logic; -- Indicates encoder cycle.
txAck : out std_logic; -- Acknowledge to validInTx.
isIdleRx : out std_logic; -- Indicates present character is idle.
isKTypeRx : out std_logic; -- 1: K type character. 0: D type character.
dataOutRx : out CbtUDataType;
validOutRx : out std_logic; -- 1: charOut is valid.
-- CDCM ports --
cdcmTxp : out std_logic; -- Connect to TOPLEVEL port
cdcmTxn : out std_logic; -- Connect to TOPLEVEL port
cdcmRxp : in std_logic; -- Connect to TOPLEVEL port
cdcmRxn : in std_logic; -- Connect to TOPLEVEL port
modClock : out std_logic -- CDCM modulated clock.
);
end CbtLane;
| Port | In/Out | Comment | |
|---|---|---|---|
| Generic port | |||
| kCdcmModWidth | - | Select 8 or 10 for CDCM-8-XX and CDCM-10-XX, respectively. | |
| kIoStandardTx | - | Tx port IO standard, e.g., LVDS. | |
| kTxPolarity | - | If it's true, the TX signal polarity is reversed. Use it when the differential signal p/n connection is inverse on FEE. | |
| genIDELAYCTRL | - | If it's true, the IDELAYCTRL primitive is instantiated in the CBT. | |
| kDiffTerm | - | Enable the internal 100-ohm termination register in FPGA. | |
| kRxPolarity | - | If it's true, the RX signal polarity is reversed. Use it when the differential signal p/n connection is inverse on FEE. | |
| kIoDelayGroup | - | Set the IODELAY_GROUP constraint to the IDELAYCTRL and IDELAYE2 primitives in the CBT. | |
| kFreqFastClk | - | The frequency value of the serial clock. It is used to determine the tap number for adjusting IDELAYE2 | |
| kFreqRefClk | - | The frequency value for IDELAYCTRL. It is used to determine the tap number for adjusting IDELAYE2 | |
| kNumEncodeBits | - | Set the payload size of the CDCM signal. Set 1 or 2. 1: CDCM-10-1.5. 2: CDCM-10-2.5. Currently, CDCM-8-2.5 is not supported. | kCbtMode | - | Set Master or Slave. The CBT runs with the designated mode. | enDebug | - | Enable preset mark_debug constraints. The debug core will be implemented. |
| IO port | |||
| srst | In | Asynchronous assert, synchronous de-assert reset. (active high) | |
| clkSer | In | Serial clock input. The clock skew must be adjusted between clkSer and clkPar. | |
| clkPar | In | Parallel clock input. The clock skew must be adjusted between clkSer and clkPar. Status, error, and Data I/F ports are synchronized with this clock. | |
| clkIndep | In | The independent clock from the clkPar. Its clock frequency should be clkPar < clkIndep < 2*clkPar. If the frequency is exactly twice of clkPar, you could get a trouble. | |
| clkIdelayRef | In | REFCLK input for IDELAYCTRL. It must be independent from clkPar. | |
| clkIsReady | In | It indicates that clkPar and clkSer are available. If this signal is low, the CBT does not start the initialization process. Set it high when the PLL output signals are well stabilized. Probably, the PLL clock signal synchronized with clkPar can be used, but the delayed one is generally preferred. | |
| initIn | In | If it is high, the CBT re-do the initialization process. This signal must be synchronized with clkPar. | |
| cbtLaneUp | Out | This goes high when the CBT becomes ready for communication after finishing the initialization process. | |
| patternErr | Out | This goes high when the waveform, which is not matched with the CDCM modulation pattern, is detected. Data is broken. | |
| bitslipErr | Out | This goes high when the reference bit pattern cannot be detected during the initialization process. Re-initialization is necessary. | |
| watchDotErr | Out | This goes high when the watch dog timer can't eat dogfood within specified time. The other side link seems to be down. | |
| isKTypeTx | In | If this is high, the current TX data is translated to a K-type character. If low, the TX data becomes a D-type character. | |
| dataInTx | In | 8-bit TX data. | |
| validInTx | In | It denotes that the current dataInTx is valid. It is the request for the CBT to transmit it. | |
| txBeat | Out | This signal goes high once per a CBT character transfer cycle for one clock cycle. It indicates a boundary of the transfer cycle. | |
| txAck | Out | The acknowledge signal respect to validInTx. This goes high when the dataInTx is latched at the same timing of the txBeat. | |
| isIdleRx | Out | This goes high when the current dataOutRx is a idle data. | |
| isKTypeRx | Out | This goes high when the current dataOutRx is a K-Type data. | |
| dataOutRx | Out | 8-bit RX data. | |
| validOutRx | Out | This goes high when the current dataOutRX valid both for D- and K-types data. | |
| cdcmTxp | Out | Transmission line positive. Connect to the toplevel port. | |
| cdcmTxn | Out | Transmission line negative. Connect to the toplevel port. | |
| cdcmRxp | In | Receive line positive. Connect to the toplevel port. | |
| cdcmRxn | In | Receive line negative. Connect to the toplevel port. | |
| modClock | Out | The CDCM modulated clock output. It is valid in the secondary mode. | |
CBT characters
The CBT character is a 10-bit internal data format in the CBT and is generated by simply adding 2-bit type header to a 8-bit data. There are K-, D-, and T-types characters. In addition, there is a IDLE character, which consists of the modulated signal with the duty ration of 50%. The T-type characters are used to control the CBT, and they are hidden inside the CBT. K-type characters are used to control the link protocol, and their bit pattern are defined in the CBT level. D-type characters are user data. The transmission request for D- and K-type characters are exclusive because it is determined by isKTypeTx signal. However, T-type character transmission can conflict with D- and K-type characters. The transmission priority among characters is defined as D < T < K characters. During the T-type character transmission, D-type character transmission is held up. The link protocol needs to keep the current dataInTx until the txAck is returned.
CDCM encode and decode
Currently, the CBT supports CDCM-10-1.5 (CDCM-8-1.5) and CDCM-10-2.5; they can transmit 1-bit binary + idle pattern and 2-bit binary + idle pattern per clkPar cycle, respectively. For details, see Ref and Ref. Since the CBT character has 10-bit data width, 10 and 5 clock cycles are necessary to send a CBT character by CDCM-10-1.5 (CDCM-8-1.5) and CDCM-10-2.5, respectively. CDCM-10-1.5 (CDCM-8-1.5) has longer latency while it provides the better jitter performance because the duty cycle change range is narrower than that of CDCM-10-2.5.
Initialization process
The CBT starts the initialization process when the following conditions are met.
- srst and initIn are low.
- clkIsReady is high.
- The clock monitor detects a clock like signal in the RX signal.
The IDELAYE2 tap number is adjusted so as to stabilize the sampled data using the idle pattern, and bitslip is performed so as to reproduce the bit pattern of 0b11111_00000. After initializing IOSERDES, some T-type characters are exchanged to confirm that both end points are actually ready for communication each other. Then, the cbtLaneUp is asserted.
Error detection
The clock monitor is always checking whether the RX signal is clock link or not. If this monitor misses the clock link RX signal, it requests to reset the CBT. If cbtLaneUp is high, it will be immediately de-asserted.
When cbtLaneUp is high, the CBT checks whether the sampled bit pattern is matched with the CDCM encoding rule or not. If a broken pattern is detected, the patternErr signal is asserted, but at this moment, the CBT is not reset. If more than 1% of received bit pattern are broken, the RX quality check monitor requests to reset the CBT.
When cbtLaneUp is high, the CBT transmits the T-type character, dogfood character, periodically. The dogfood character resets the watch dog timer in other side. If the watch dog timer can't eat dogfood within specified time, the watchDogErr goes high, and the watchdog timer requests to reset the CBT.
MIKUMARI link protocol
The MIKUMARI link is a link layer protocol to establish the communication link between two end points, which are physically connected. The roles of the MIKUMARI link are as follows.
- Define the K-type characters; these are characters for the link control.
- Define a frame structure, called the MIKUMARI frame, for the data transmission
- One-shot pulse transmission with fixed latency using K-type characters.
Interface of MIKUAMRI link
The top-level block of the MIKUMARI link is MikumariLane. The global parameters for the MIKUMARI link are defined in defMikumari.vhd. The MikumariLane's entity port structure is as follows.
entity MikumariLane is
generic
(
-- CBT --
kNumEncodeBits : integer:= 2;
-- Scrambler --
enScrambler : boolean:= true;
-- DEBUG --
enDEBUG : boolean:= false
);
port
(
-- SYSTEM port --------------------------------------------------------------------------
srst : in std_logic; -- Asynchronous assert, synchronous de-assert reset. (active high)
clkPar : in std_logic; -- From BUFG
cbtUpIn : in std_logic; -- Cbt lane up signal
linkUp : out std_logic; -- Mikumari link is up
-- TX port ------------------------------------------------------------------------------
-- Data I/F --
dataInTx : in CbtUDataType; -- User data input.
validInTx : in std_logic; -- Indicate dataIn is valid.
frameLastInTx : in std_logic; -- Indicate current dataIn is a last character in a normal frame.
txAck : out std_logic; -- Acknowledge to validIn signal.
pulseIn : in std_logic; -- Pulse input. Must be one-shot signal.
pulseTypeTx : in MikumariPulseType; -- 3-bit short message to be sent with pulse.
busyPulseTx : out std_logic; -- Under transmission of previous pulse. If high, pulseIn is ignored.
-- Cbt ports --
isKtypeOut : out std_logic;
cbtDataOut : out CbtUDataType;
cbtValidOut : out std_logic;
cbtTxAck : in std_logic;
cbtTxBeat : in std_logic;
-- RX port ------------------------------------------------------------------------------
-- Data I/F --
dataOutRx : out CbtUDataType; -- User data output.
validOutRx : out std_logic; -- Indicate current dataOut is valid.
frameLastRx : out std_logic; -- Indicate current dataOut is the last data in a normal frame.
checksumErr : out std_logic; -- Check-sum error is happened in the present normal frame.
pulseOut : out std_logic; -- Reproduced one-shot pulse output.
pulseTypeRx : out MikumariPulseType; -- Short message accompanying the pulse.
-- Cbt ports --
isKtypeIn : in std_logic; --
cbtDataIn : in CbtUDataType;
cbtValidIn : in std_logic
);
end MikumariLane;
| Port | In/Out | Comment | |
|---|---|---|---|
| Generic port | |||
| kNumEncodeBits | - | Payload size of the CDCM signal. Set 1 or 2. 1: CDCM-10-1.5. 2: CDCM-10-2.5. Set the same value given for the CBT. | |
| enScrambler | - | If it's true, data scrambler is enabled. Enabling the scrambler is recommended for the better jitter performance. | enDebug | - | Enable preset mark_debug constraints. The debug core will be implemented. |
| IO port | |||
| srst | In | Asynchronous assert, synchronous de-assert reset. (active high) | |
| clkPar | In | Parallel clock input; it is the identical clock as for the CBT. | |
| cbtUpIn | In | cbtLaneUp signal from the CBT. Connect to the cbtLaneUp port directly. | |
| linkUp | Out | This goes high when the link connection is established. If this is high, access to the data I/F ports are valid. | dataInTx | In | 8-bit user data input, the frame payload. |
| validInTx | In | It denotes that the current dataInTx is valid. It is the request for the MIKUMARI link to transmit it. | |
| frameLastInTx | In | This signal indicates that the current dataInTx is last 1-byte in this frame transmission cycle. If the MIKUMARI link detects this signal, the frame checksum and the frame-end K-type character (FEK) are inserted. | |
| txAck | Out | The acknowledge signal respect to validInTx. This goes high when the dataInTx is latched. | |
| pulseIn | In | One-shot pulse input, equal to the pulse transmission request. If the MIKUMARI link detects this signal when the busyPulseTx is low, the pulse K-type character is inserted. Pulse transmission request has higher priority than the validInTX. Pulse width must be one-shot, 1 clock cycle. | |
| pulseTypeTx | In | Pulse type input. This type value is transmitted together with a one-shot pulse. Currently, the pulse type width is 3-bit, and the 8-types of pulses can be transferred. The type value is latch when the pulseIn is high. | |
| busyPulseTx | Out | Busy signal for pulse transmission. When it is high, the pulseIn input is ignored. | |
| isKtypeOut | Out | It indicates that the current cbtDataOut is a K-type character. Connect to isKtypeTx of the CbtLane. | |
| cbtDataOut | Out | 8-bit data for the CBT. Connect to dataInTx of the CbtLane. | |
| cbtValidOut | Out | It indicates that the current cbtDataOut is valid. Connect to validInTx of the CbtLane. | |
| cbtTxAck | In | Acknowledge from the CBT respect to cbtValidOut. Connect to txAck of the CbtLane. | |
| cbtTxBeat | In | The boundary of the CBT character transfer cycle. Connect to txBeat of the CbtLane. | |
| dataOutRx | Out | 8-bit user data output, received frame payload. | |
| validOutRx | Out | Data valid. If this is high, the current dataOutRx is valid. | |
| frameLastRx | Out | This goes high when the current dataOutRx is last 1-byte of the received frame payload. | |
| checksumErr | Out | If it is high, the checksum miss match is happened in the present MIKUMARI frame. | |
| pulseOut | Out | Received one-shot pulse output. | |
| pulseTypeRx | Out | Received pulse type value. The value when pulseOut is high is valid. | |
| isKtypeIn | In | It indicates that the current dataOutRx is a K-type character. Connect to isKTypeRx of the CbtLane. | |
| cbtDataIn | In | 8-bit data from the CBT. Connect to dataOutRx of the CbtLane. | |
| cbtValidIn | In | It indicates that the current cbtDataIn is valid. Connect to validOutRx of the CbtLane. | |
MIKUMARI frame and data transmission
The MIKUMARI protocol transmits the data using a simple frame structure, called the MIKUMARI frame. The frame consists of four blocks as follows.
- Frame start K-type character (FSK)
- Arbitral length data body (payload)
- 8-bit checksum
- Frame end K-type character (FEK)
The frame structure is similar that of Xilinx Aurora 8b/1b protocol. Inserting FSK, FEK, and checksum are done by the MIKUMARI link, and later two are inserted after detecting frameLastInTx. At the receiver side, frameLastOutRx assertion and checksum calculation are performed after detecting the FEK. Note that 8-bit checksum data does not appear from dataOutRx. It is internally used. About details of the frame structure, see also Ref.
Since the frame body and 8-bit checksum data are D-type character, their transmission request can be blocked by the T-type character transmission by the CBT. If it is blocked, the txAck is not returned at the expected timing, the upper layer protocol needs to keep the current dataInTx and validInTx until txAck is returned. It is defined that pulse K-type characters have higher priority to other K-type character in this protocol. Thus, FSK and FEK insertion can be delayed by pulse transmission request. Therefore, the data transmission latency using the MIKUMARI frame is not perfectly fixed. Use the pulse transfer function for usages where arrival times must be strictly controlled.
The data interface of the MIKUMARI link is also similar to that of Xilinx Aurora 8b/1b protocol (AXI4-stream). As there is the CBT character transmission cycle, txAck signal is used instead of tready signal.
The time chart for MIKUMARI data transmission is shown in the figure. The upper layer protocol sets the next data after detecting txAck high. If the data is last 1-byte of the frame body, assert frameLastInTx and keep it high until the next txAck high. The data 'D' is the 1st 1-byte of the data body in the next frame. We can suspend the data transmission by de-asserting validInTx. If validInTx is low at the txBeat timing, idle character is sent.
The time char for MIKUMARI data receive is shown in the figure. The validOutRx goes high when the dataOutRx is valid. If the dataOutRx is the last 1-byte of the frame, frameLastOutRx goes high at the same timing of validOutRx. After that, as checksum and K-type character receive continues, user data in the next frame will not appear immediately. Sometimes, validOutRx will not go high at the expected timing due to idle character receive or conflicting with K- or T-type characters.
Pulse transmission
The pulse transmission with pulse types is realized by using K-type characters. The pulse type and the transmission request timing are encoded to a K-type character, and it is transmitted with highest priority. The receiver side decodes the received pulse K-type character and reproduces the pulse timing and the pulse type value. While the CBT character transmission is accepted once per 5 or 10 clock cycles, the pulse transmission can be requested at any timing. Due to the internal process realizing this feature, an additional idle character transmission is necessary after the pulse K-type character transmission. Therefore, the busy length for a pulse transfer is 10 and 20 clock cycles for CDCM-10-2.5 and CDCM-10-1.5 (CDCM-8-1.5), respectively. This limits the maximum pulse frequency. In addition, transmission of several pulse types at the same timing is also impossible.
Due to the limitation of the range of expressible bit combinations using 8-bit, only the pulse K-type characters do not guarantee the DC balance of the signal on the transmission line. If the averaged duty ratio of the CDCM modulated clock is not 50%, the recovered clock phase is systematically shifted depending on the averaged duty ratio. This effect is visible when the pulse transfer rate is high. See Ref for the details.
Data scrambler
The MIKUMARI link supports the data scrambling based on PRBS16. Since the data scrambler guarantees the DC balance on average and there is no demerit, the author strongly recommend to use it.
Checksum error
The checksumErr goes high, if the received checksum value and the calculated value is not the same. The MIKUMARI link do nothing even if the checksum error is detected. When the error is detected, processing is left to the upper layer protocol.
MikumariBlock
The MikumariBlock is a wrapper module including the CbtLane and the MikumariLane. The intermediate signals between the CBT and the MIKUMARI link are hidden. For users, the author recommends to use the MikumariBlock. The entity port structure is shown as follows. The almost all MikumariBlock entity ports are directly connected to the CBT and the MikumariLane entity ports, however, the clock synchronization is done inside the MikumariBlock. Therefore, the reset input to the MikumariBlock is asynchronous.
entity MikumariBlock is
generic (
-- CBT generic -------------------------------------------------------------
-- CDCM-Mod-Pattern --
kCdcmModWidth : integer; -- # of time slices of the CDCM signal
-- CDCM-TX --
kIoStandardTx : string; -- IO standard of OBUFDS
kTxPolarity : boolean:= FALSE; -- true: inverse polarity
-- CDCM-RX --
genIDELAYCTRL : boolean; -- If TRUE, IDELAYCTRL is instantiated.
kDiffTerm : boolean; -- IBUF DIFF_TERM
kRxPolarity : boolean; -- If true, inverts Rx polarity
kIoStandardRx : string; -- IOSTANDARD of IBUFDS
kIoDelayGroup : string; -- IODELAY_GROUP for IDELAYCTRL and IDELAY
kFreqFastClk : real; -- Frequency of SERDES fast clock (MHz).
kFreqRefClk : real; -- Frequency of refclk for IDELAYCTRL (MHz).
-- Encoder/Decoder
kNumEncodeBits : integer:= 2; -- 1:CDCM-10-1.5 or 2:CDCM-10-2.5
-- Master/Slave
kCbtMode : string;
-- DEBUG --
enDebugCBT : boolean:= false;
-- MIKUMARI generic --------------------------------------------------------
-- Scrambler --
enScrambler : boolean:= true;
-- DEBUG --
enDebugMikumari : boolean:= false
);
Port (
-- System ports -----------------------------------------------------------
rst : in std_logic; -- Asynchronous reset input
clkSer : in std_logic; -- Slow clock
clkPar : in std_logic; -- Fast clock
clkIndep : in std_logic; -- Independent clock for monitor in CBT
clkIdctrl : in std_logic; -- Reference clock for IDELAYCTRL (if exist)
clkIsReady : in std_logic; -- Flag to indicate slow and fast clocks are ready
initIn : in std_logic; -- Redo the initialize process
TXP : out std_logic; -- CDCM TXP port. Connect to toplevel port
TXN : out std_logic; -- CDCM TXN port. Connect to toplevel port
RXP : in std_logic; -- CDCM RXP port. Connect to toplevel port
RXN : in std_logic; -- CDCM RXN port. Connect to toplevel port
modClk : out std_logic; -- Modulated clock output
-- CBT ports ------------------------------------------------------------
laneUp : out std_logic; -- CBT link connection is established
pattErr : out std_logic; -- CDCM waveform pattern is broken
watchDogErr : out std_logic; -- Watchdog timer alert
-- Mikumari ports -------------------------------------------------------
linkUp : out std_logic; -- MIKUMARI link connection is established
-- Data IF TX --
dataInTx : in CbtUDataType; -- User data input.
validInTx : in std_logic; -- Indicate dataIn is valid.
frameLastInTx : in std_logic; -- Indicate current dataIn is a last character in a normal frame.
txAck : out std_logic; -- Acknowledge to validIn signal.
pulseIn : in std_logic; -- Pulse input. Must be one-shot signal.
pulseTypeTx : in MikumariPulseType; -- 3-bit short message to be sent with pulse.
busyPulseTx : out std_logic; -- Under transmission of previous pulse. If high, pulseIn is ignored.
-- Data IF RX --
dataOutRx : out CbtUDataType; -- User data output.
validOutRx : out std_logic; -- Indicate current dataOut is valid.
frameLastRx : out std_logic; -- Indicate current dataOut is the last data in a normal frame.
checksumErr : out std_logic; -- Check-sum error is happened in the present normal frame.
pulseOut : out std_logic; -- Reproduced one-shot pulse output.
pulseTypeRx : out MikumariPulseType -- Short message accompanying the pulse.
);
end MikumariBlock;
